128 lanes isolated digital output, PCI-1758 for 64 channels)

Output channel high-voltage isolation (2500 volts DC)

Wide output range: 5-40 volts DC

Isolated Output Channel High Flood Current (up to 90mA/channel)

Port current protection

BoardID™ switch

Read back the output state

The digital output value retained after the thermal system is reset

Programmable on state

Watch dog timer

128 Isolated Digital Input Channels (PCI-1758UDIO Bit 64)

Wide input range: 5-25 volts DC

High ESD protection, digital filtration function

Interrupt handling capacity for each channel
